| Model | LKAD054D | |||||
| 输入 Input | AC电压范围/AC Voltage range | 120V | ||||
| 频率/Frequency | 50/60hz | |||||
| 谐波/THD | ||||||
| 功率因数/Power factor | 0.9/110VAC | |||||
| 输出 Output | 额定电压/Rated voltage | 12V | ||||
| 空载电压/No-load Voltage | 12.3V | |||||
| DC电压范围/DC voltage range | 11.8-12.2V | |||||
| DC电流范围/DC current range | 4A | |||||
| 电流精度/Current precision | (+/-)3% | |||||
| 额定功率/Rated power | ||||||
| 开机延时/Setup Time | ≤0.5s/230VAC | |||||
| 使用环境 Environment Requirements | 工作温度/湿度要求 Operating Temp./RH | -30～+45℃/20～95% | ||||
| 储存温度,湿度要求 Storage Temp./RH | -40～+80℃/10～95% | |||||
| 安全和电磁兼容 | 认证编号/Certificate | |||||
| 其他 | 尺寸/Size | L87.5*W36.3*H24mm | ||||
| 重量/Net weight | 69g | |||||
